P/N: SHM12-C03
Pitch: 2.00 mm
Height: 3.60/4.10/5.10 mm
Number of contacts:06
Type: SMT
Electrical
Current Rating: 0.05A
Voltage Rating: 12V
Contact Resistance: 100mΩ
Withstanding Voltage: 100V AC/1min
Insulator Resistance: 50MΩ
Materiral
Cover: Copper Alloy
Stem: NYLON
Contact: Copper Alloy
Housing: NYLON
Shell: SUS
Terminal: Copper Alloy
